OPERATOR’S MANUAL
INSTALLATION
OPERATOR SWITCH MODULE MOUNTING
BRACKET
The Operator Switch Module Bracket attaches the Operator Switch Module
to the tablet and includes the following components:
• Main switch module mounting bracket
• 3 Hex nuts
• 4 washers
• 3 nuts/3 washers
OPERATOR SWITCH MODULE BRACKET AND TABLET
MOUNTING PLATE
Attach Tablet Mounting Plate to the Operator Switch Module Bracket:
1. Remove the 4 screws from the back of the tablet plate
2. Align switch module bracket holes with the plate holes.
3. Secure the bracket and plate with the 4 screws.
Attach Switch Module to Operator Switch Module Bracket:
4. Align stud bolts (3) to the bracket opening and insert the switch
module.
5. Align switch module so the connectors insert through the module
bracket connector opening and the (3) switch module stud bolts insert
through the bolt holes of the bracket assembly.
6. Secure switch module to the bracket using (3) hex nuts and washers.
Flex4 Pro
TM
Control System
6010541 Rev A
INSTALLATION / 17
