OPERATOR’S MANUAL
(3)
ALARMS
Alarm text appears in this window when user-defined parameters are
outside of limits set.
(4)
ACCESSORY SENSORS/ALARMS
•
Digital and analog accessory sensors enabled will display sensor
status in the lower display window.
•
Accessory alarms display in this area with a one beep audible alarm.
The sensor status remains in red until issue is resolved.
(5)
GROUND SPEED/TIME/DATE/BATTERY INDICATOR
•
Ground speed is independent of product application and displays
actual ground speed in the lower display window. A manual ground
speed setting also appears in this location, when enabled.
•
Current time and date displays below the ground speed window.
•
Battery status bar indicates battery charge status. The system should
maintain a full charge in normal operating conditions. If the battery
discharges during normal operation, there could be an issue with the
system cabling or the DC-DC converter.
DISPLAY SETTINGS (CAMERA/DISPLAY/ALARMS)
Display settings adjust the characteristics of appearance and volume of the
tablet:
•
Camera settings (appearance of the camera window display on the
tablet)
•
Display brightness (lightness/darkness of screen)
•
Alarm volume (high/low adjustment of audible alarm when error
occurs)
To change a Display Setting:
1.
At the Operate screen, press the Display Settings button.
2.
To modify a display setting, press the Camera, Display Brightness, or
Alarm Volume button.
3.
Press the Increase button or Decrease button to adjust the bar graph.
Each time the button is pressed the setting changes and is visible on
the screen with a percent adjustment.
NOTE: Pressing the Back button
returns to previous menu.
Camera settings, display brightness, and alarm volume values are adjusted
in bar graph form.
–
The Camera Settings bar graph indicates the appearance of the
camera window on the display allowing adjustment to brightness,
contrast, saturation, hue, and rotation.
–
The Display Brightness bar graph indicates the brightness level of
the display. A full bar graph indicates the most brightness. The
brightness changes each time the Increase/Decrease buttons are
pressed.
–
The Alarm Volume bar graph indicates the volume level for the
audible alarm. An empty bar graph indicates the lowest volume;
Flex4 Pro
TM
Control System
6010541 Rev A
OPERATE SCREEN OVERVIEW / 29
