OPERATOR’S MANUAL
The Rate Control Harness provides a connection to the following inputs:
–
1 granular control channel
–
1 liquid control channel (prewet or anti-ice)
–
1 auxiliary/spinner control channel (liquid or granular)
–
1 auxiliary channel (liquid or granular channel)
–
2 application rate sensors
–
4 hydraulic valves (PWM)
–
1 down pressure sensor
–
1 control valve (Servo)
–
2 flow meters
–
1 gate height sensor
–
1 ground speed sensor
–
1 remote on/off
–
2 digital sensors
–
1 hopper level sensor
–
1 tank level sensor
–
2 6-pin Servo connectors
–
1 road/air temperature sensor adapter (optional)
5.
Install sensors, valves, etc. per the instructions included with the items.
6.
Install PWM valve assembly and feedback sensor for each control loop
and connect the devices to their respective inputs on the harness
making certain to match PWM 1/Servo 1 with FB1, PWM2/Servo 2 with
FB2, etc.
7.
Secure any unused and excess cable lengths where necessary.
OUTPUT MODULE
The Output Module is an auxiliary to the Rate Control Module to drive
additional accessories installed on the vehicle such as boom section shutoff
valves, open and close V-Box gates, switching valves for front/rear
conveyors, switching valves for left/right discharge cross conveyors, and
accessory 12 volt switched output.
1.
Select an area on the vehicle chassis to mount the module that allows
for easy hookup and access. Extensions may be used to reach
members installed on remote areas of the vehicle.
2.
The module can be mounted in the same orientations as the rate
control module as illustrated in (Figure 7).
Flex4 Pro
TM
Control System
6010541 Rev A
COMPONENT OVERVIEW / 11
