OPERATOR’S MANUAL
SYSTEM PROGRAMMING
The Flex4 Pro
TM
Control system has configuration screens to enter
user-defined rates, limits, and parameters for regulating system product
application. A keyboard is required for programming.
NOTE: After plugging in the keyboard,
the Flex4 Pro
TM
tablet screen
must be touched first before the
keyboard becomes active and
usable.
Four channels are available for material and spinner control:
•
(1) dedicated granular channel (F2)
•
(1) dedicated liquid channel (F3)
•
(1) auxiliary channel for granular/liquid or spinner control (F4)
•
(1) auxiliary channel for liquid or granular (F5)
Please read "Appendix A: Channel Linking Conditions and
Recommendations" prior to setting up your material application controls.
Additional setup for proper system operation includes performing:
•
System Calibration (F6)
•
Diagnostics (F7)
•
Ground Speed Setup (F8)
•
Accessory Sensor Setup (F9)
•
System Setup (F10)
•
Output Module Setup (F11)
•
Data Logging (F12)
IMPORTANT: System programming MUST be conducted before
performing a system calibration. Accurate system
calibration constants are determined through regular
calibration routines. Known constants can be entered
reducing the calibration procedures required.
Calibration corrections can be performed anytime to
fine-tune accuracy.
OPERATE MODE (F1)
The Operate screen can be accessed at any time during programming by
pressing the F1 function key. No programming functions are available at this
screen but can be used to verify active selections.
The Operate screen shows programmed values for spreading material and
provides access to the following functions:
•
Material Selection screen
•
Unloading Material screen
•
Tablet Display settings
•
Current Totals screen
Refer to the Operation section for detailed function descriptions.
ANTI-ICE BUTTON MODE FEATURE
A special mode is available in those situations where toggling
between turning on anti-ice and turning off liquid/granular happens
simultaneously by pressing an Anti-Ice button on the Operate screen.
Flex4 Pro
TM
Control System
6010541 Rev A
SYSTEM PROGRAMMING / 53
