OPERATOR’S MANUAL
GATE HEIGHT CONTROL
Select Yes to control raising and lowering the gate height from the cab.
INC/DEC PWM
The PWM percentage entered determines the PWM signal level that is sent
to the electric actuated cylinder when the gate increase or decrease button
is pressed from the main Flex4 Pro
TM
tablet Operate screen. The higher the
PWM signal is set, the faster the gate opens or closes.
INC/DEC TIME
The time entered determines how long the PWM signal is sent to the
electric actuated signal each time the gate increase or decrease button is
pressed from the Flex4 Pro
TM
tablet Operate screen. The higher the time is
set, the longer the gate continues to open or close upon a single press of
the gate increase/decrease button.
Example: PWM percentage set at 40 and time set at 2 seconds. Pressing
the Gate Increase button sends a 40% PWM signal to the electric actuated
cylinder for 2 seconds.
92 / SYSTEM PROGRAMMING
Flex4 Pro
TM
Control System
6010541 Rev A
