TransPort WR44 RR hardware
Digi TransPort User Guide 76
Ethernet connectors
Ethernet connector M12-4 pin, D Coded
Ethernet connector M12-8 pin, A Coded
TransPort WR44 RR hardware specifications
Complete, updated specifications of the Digi TransPort WR44 RR device and accessories are
available on the Digi website, www.digi.com.
• To view the Digi TransPort WR44 RR Hardware Specifications, go to the Specifications tab of
the TransPort WR44 RR product page.
• To view available accessories, including cables and antennas for the Digi TransPort WR44 RR,
go to the Models tab for the TransPort WR44 RR product page and click View Accessories.
Pin RJ45 Signal Notes
1 1 TX+ Twisted Pair
22TX-
3 3 RX+ Twisted Pair
46RX-
Pin RJ45 Signal Notes
4 6 RX- Twisted Pair
63RX+
5 1 TX+ Twisted Pair
82TX-
1N/C
2N/C
3N/C
7N/C
