Control|24 Guide132
Sys Info Page
The Sys Info page contains information about
the hardware and firmware revisions on Con-
trol|24, as well as the Ethernet ID.
To access the Sys Info page:
■ Press UTILITY > Sys Info.
Monitor Pages
The Monitor pages contain items which are spe-
cific to Control|24’s analog monitoring section.
To access the Monitor pages:
■ Press UTILITY > Monitor.
STEREO Page
“Single” Mode In Single mode, only one moni-
tor section choice can be active at a time while
in Stereo mode (i.e., while not in a surround
mode). This is the default mode.
“Multi” or Multiple Mode In Multi mode, you
can select multiple sources in an additive fash-
ion, and thereby monitor multiple sources si-
multaneously while in Stereo mode.
To set stereo mode:
1 Press UTILITY > Monitor > STEREO.
2 Select Single or Mult.
3 When finished, press EXIT.
Talkback Page
This mode allows you to specify the settings for
talkback mic operation. It provides a way to se-
lect whether the internally-mounted talkback
mic or an external mic is active. For more infor-
mation, please refer to “Talkback and Listen-
back” on page 58.
To select talkback mode:
1 Press UTILITY > TALKBACK.
2 Choose External or Internal.
3 When finished, press EXIT.
Test Pages
The Test pages include menu items for testing
various components and sections on Con-
trol|24.
To access the Test pages:
■ Press UTILITY > Test.
LED Test Pages
The LED test mode allows you to check that the
LEDs on the surface are functioning properly.
To access the LED test pages:
■ Press UTILITY > Test > LED.
