Chapter 8: Control Room Monitor Section 55
Selecting Monitor Modes
Control|24 supports Stereo, LCRS, and 5.1 Sur-
round modes.
Stereo Mode Settings
Stereo monitoring mode can be configured for
Single-source, or Multi-source monitoring.
If in “Single” source monitoring mode, only one
input source can be engaged at a time. To mon-
itor more than one source input, Control|24
must be in either “Multi” mode, or Surround
mode.
To select Source Monitoring Mode:
1 Press the Utility switch.
2 Select “Monitor.”
3 Select “Stereo.”
4 Select either “Single” or “Multi” mode.
5 Select “Exit” or press the Utility switch again
to return to normal operation.
Monitor Input Source Select
Switches
The Control Room Monitor section comprises a
set of six possible stereo monitor sources for
Control|24 in stereo mode, or as master source
controls for the matrix inputs in Surround
mode.
To engage an Input Source:
■ Press the switch in the Control Room Monitor
section that corresponds to the desired input
source. If Control|24 is in Single-source stereo
mode, selecting any input source deselects the
current source. If configured for multi-source
stereo mode, selecting any input source adds
that source signal to the current input source
mix.
Pro Tools Stereo Source Pairs
