C
HAPTER
24
| Remote Monitoring Commands
– 799 –
show running-config command will display a message indicating that
this index is not available for the port to which is normally assigned.
For example, if control entry 15 is assigned to port 5 as shown below,
the show running-config command will indicate that this entry is not
available for port 8.
Console(config)#interface ethernet 1/5
Console(config-if)#rmon collection history controlEntry 15
Console(config-if)#end
Console#show running-config
!
interface ethernet 1/5
rmon collection history controlEntry 15 buckets 50 interval 1800
...
interface ethernet 1/8
no rmon collection history controlEntry 15
EXAMPLE
Console(config)#interface ethernet 1/1
Console(config-if)#rmon collection history controlentry 21 owner mike buckets
24 interval 60
Console(config-if)#
rmon collection rmon1 This command enables the collection of statistics on a physical interface.
Use the no form to disable statistics collection.
SYNTAX
rmon collection rmon1 controlEntry index [owner name]
no rmon collection rmon1 controlEntry index
index – Index to this entry. (Range: 1-65535)
name – Name of the person who created this entry.
(Range: 1-127 characters)
DEFAULT SETTING
Enabled
COMMAND MODE
Interface Configuration (Ethernet)
COMMAND USAGE
u By default, each index number equates to a port on the switch, but can
be changed to any number not currently in use.
u If statistics collection is already enabled on an interface, the entry must
be deleted before any changes can be made with this command.
u The information collected for each entry includes:
input octets, packets, broadcast packets, multicast packets, undersize
packets, oversize packets, fragments, jabbers, CRC alignment errors,
collisions, drop events, and packets of specified lengths
