Dobot M1 User Guide 5 Installation and Commissioning
Issue V1.3.4 (2019-05-23) User Guide Copyright © Yuejiang Technology Co., Ltd
47
Figure 5.13 Direct connection
If the SN number of Dobot M1 is DT211812xxx and later numbers, please connect them
as the flowing steps. Please check the SN number on the M1Studio > Help > About
M1Studio page.
xxx is a random number, please replace it based on site requirements.
The forced configuration page is displayed.
NOTICE
Please make sure that the IP address of PC belongs to class C networks when
configuring the IP address. Otherwise, the forced configuration will fail.
Class C IP addresses range: 192.0.0.0 - 223.255.255.255. Default subnet mask:
255.255.255.0.
Forced configuration function is recommended only when a PC controls a Dobot
M1. As a PC controls multiple Dobot M1 simultaneously, all the IP addresses will
be modified when you modify one of IP addresses by forced configuration.
If the A9 firmware version is 02005900 or earlier version, the DHCP function will
