Domino A-SERIES

REPAIR
8--20 27080 Issue 1 Sept 98
Jet Alignment
in Charge
Electrode
Jet Alignment
with Deflector
Plates
Jet Alignment in Gutter
Jet
Head Alignments
Jet to be set 25% of
gutter diameter from
gutter wall
75%
ID
TP2145--1
1mm
1mm
90%
ID
Pinpoint
Pinpoint
