Domino A-SERIES

OPTIONS
27080 Issue 1 Sept 98 10--19
PELTIER OPTION KIT
The Peltier assembly is fitted to reduce evaporation lossfrom thevent.
The resulting liquid is passed back into the make--up reservoir. It is
fittedas standardonA300printersandisanoption for A200 andA100
printers.
The Kit consists of a Peltier assembly and condenser fitted onto a
bracket which is mounted to the side of the inksystem, next to the ink
managementblock. FitthePeltierconnectorintoPL7oftheInkSystem
Interface PCB (inside the ink cabinet).
Peltier Option Kit
MG173_1
Peltier
Assembly
Condenser
Mounting
Bracket
Peltier
Assembly
Condenser
Mounting
Bracket
MG171_1
Spares List --Peltier Option Kit -- 37751
Peltier Assembly (only)-- 37725
