OPERATION
3--4 27080 Issue 1 August 98
INK RESERVOIR REPLACEMENT
ThemessagesInkchangeneededinlessthan 24hoursand,later,Inkchange
needed in less than 2 hours will appear near the end of the reservoir life
(If a long--life system is being used, these warnings will appear at 300
hours and 24 hours before the end of reservoir life). Printing will not
continue beyond the expiry of the reservoir life.
It is necessary to enter the reservoir quality code of the new reservoir
and reset the reservoir replacement alarms, using the following
procedure:
(1) Press the Service key and enter the password if required.
(2) Use the key bar scroll keys to find the Change Resvr option at the
bottom of the screen.
(3) Pressthe functionkeymarkedbyChangeResvr andthescreenwill
change to show a prompt requesting input of the Quality Code
printed on the label of the new ink reservoir.
(4) Type in the reservoir quality code.
(5) Press the function key marked OK.
If the correct code is typed in, the reservoir run time will be reset and
the alarms cancelled. Proceed to step (6).
If the number is typed inaccurately, it can be corrected by typing in
again. If an invalid code number is typed, the number will not be
accepted and messages in the information bar will indicate the
problem, e.g. Incorrect ink type, Ink out of date, or Resvr already used (an
old reservoir number). The offending reservoir should be replaced.
(6) Shut down the printer using the proper procedure.
(7) Switch off the printer.
Replace the reservoir as follows.
Notes (1) Tissue will be required for this procedure.
(2) The make--up reservoir is non--replaceable.
Removethe inkcartridge(seediagramonthenextpage). Unscrewthe
manifold locking ring, lift themanifoldoutofthereservoir andsecure
themanifoldintothemanifoldretainerinsidethetopoftheinkcabinet.
Fitacaptothereservoir. Pushthemetalreservoirretainingbarandpull
the reservoir forward to remove.
To fit a new reservoir, reverse the above procedure.
Change
Resvr
OK
To Next Page
