PRINTER SPECIFICATION
Print Head
Standard Finish: Aluminium alloy, Tufram coated
Dimensions: Width: 40mm (1.575”)
Depth: 42.5mm (1.673”)
Height: 280.5mm (11.05”)
Weight: 1.0kg (2.2lbs)
Nozzle size:
Pinpoint only:
60 or 75 micron
40 micron
Spacing from print surface:
Pinpoint only:
12mm (0.47”) nominal
4mm (+/-- 1mm)
Working height relative to
cabinet base:
3m conduit: +/--2m (8ft 2ins)
6m conduit: +/--3m (10ft) (A300/A200
only)
Conduit Length: 3 or 6 metres (10ft and 20ft)
A300 Pinpoint and A100: 3m only
Cabinet
Standard Finish: Brushed 316 stainless steel (A300)
Brushed 304 stainless steel (A200 & A100)
IP Rating: A300 is IP65 (1977)
A200/A100 are IP53 (1977)
Dimensions (A300 &
A200):
Width: 475mm (18.7”) --not incl. handles
Depth: 245mm (9.65”) --not incl. front panel
Height: 715mm (28.15) --not incl. feet
Weight (A300 & A200)
(incl. fluids):
36kg (79lbs)
Dimensions (A100): Width: 450mm (17.7”) -- not incl. handles
Depth: 245mm (9.46”)
Height: 650mm (25.6”)
Weight (A100) (incl. fluids): 33kg (72.6lbs)
Control Panel: Polyester, Membrane touch button
For cabinet and print head installation dimensions, see Installation
page A--13.
Data Input (Optional)
Interface: Serial, RS232, RS485
Rate: 110 -- 38.4kBaud software configurable
