Domino A-SERIES User Manual

APPENDIX A : INSTALLATION
A--18 27080 Issue 1 Sept 98
Electrical Supply
WARNING: Thecabinetmustbeproperlyearthedforthe safety
of personnel working on the printer.
CAUTION Inadequate earthing could result in unreliable
operation or component failure.
Theprintershouldbeconnectedusingasuitableplugandsocketoutlet
which is accessible and close to the equipment, so that power can be
quickly disconnected. If a fused power connector is used,it shouldbe
fitted with a 5A fuse. If a fused power connector is not used, then the
supply circuit should have a circuit breaker or fuse rated at 5A.
Thesupply mustbefreefromelectricalnoise. Domino cangiveadvice
on suitable devices to ensure trouble--free operation.
EXTERNAL CONNECTIONS
Power
Switch
E
x
t
e
r
n
a
l
C
o
n
n
e
c
t
i
o
n
s
Power
Connector
Beacon
Connector
(Optional)
Alarms
Connector
(Optional)
Product
Detector
/Shaft
Encoder
Connectors
Comms Connector
(Optional)
User Port Connector
(Optional)
MG001--1
DominoA--Seriesprintersrequirethefollowing a.c.singlephase,three
wire supply:
90V -- 132V (nom. 120V), 200VA, 50/60Hz, or
180V -- 264V (nom. 220V), 200VA, 50/60Hz,
