Vigor3900 Series User’s Guide
183
Use IP Alias
When All is selected as WAN Profile, such feature is
unavailable.
Use the drop down list to select the type you want.
Single Alias – You have to type one IP address used for IP
Alias.
All – All the IP address can be treated as IP Alias.
Alias
WAN IP alias that can be selected and used for port
redirection. Before using it, please go to WAN>>General
Setup and enable the wan1 profile. Add several IP
addresses under Static mode for wan1.
Protocol
Choose the protocol used for the entry.
Source IP
Choose the source IP object for port redirection.
Public Port Start/
Public Port End
It is available when Range to One or Range to Range
(port) or Range to Range (IP) is selected as Port
Redirection Mode.
Type the starting/ending number of the public port.
For Range-to-One, set both Start and End values with the
same value.
Private IP
Specify the private IP address of the internal host providing
the service. Simply type the private IP used for this entry.
Private IP Start /
Private IP End
It is available when Range to Range (IP) is selected as Port
Redirection Mode.
Type the starting/ending IP address.
Private Port
Type a port number for such profile.
Apply
Click it to save and exit the dialog.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all the settings and click Apply.
