Draytek VigorAP 906 User Manual

94
III-1-5 Configuration Backup
Such a function can be used to backup/restore the VigorAP 906 settings.
Available settings are explained as follows:
Item Description
Restoration Browse - Click it to specify a file to be restored.
Password (optional) – Enter a password for configuration
restoration.
Restore – Click it to restore the configuration file to VigorAP.
Backup Perform the configuration backup of this device.
Protect with password- For the sake of security, the configuration
file for the access point can be encrypted.
Password – Type several characters as the password for encrypting
the configuration file.
Confirm Password – Type the password again for confirmation.
Backup – Click it to backup the configuration file.
Follow the steps below to backup your configuration.
1. Go to System Maintenance >> Configuration Backup.
2. If required, check the box of Protect with a password and enter the password.
3. Click Browse to get into the following dialog. The configuration will download automatically to
your computer as a file named config.cfg.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
