Draytek VigorAP 906 User Manual

36
II-3-2 Security
This page allows you to set security with different modes for SSID 1, 2, 3, and 4 respectively. After
configuring the correct settings, please click OK to save and invoke it.
By clicking the Security Settings, a new web page will appear so that you could configure the
settings.
Available settings are explained as follows:
Item Description
Mode
There are several modes provided for you to choose from.
Below shows the modes with higher security;
 WPA3 Personal, WPA3/WPA2 Personal, WPA2 Personal,
WPA2/WPA Personal - Accepts only WPA clients and the
encryption key should be entered in PSK. The WPA encrypts
each frame transmitted from the radio using the key, which
either PSK (Pre-Shared Key) entered manually in this field below
or automatically negotiated via 802.1x authentication.
The WPA encrypts each frame transmitted from the radio using
the key, which either PSK (Pre-Shared Key) entered manually in
this field below or automatically negotiated via 802.1x
authentication. Select WPA, WPA2, or Auto as WPA mode.
 WPA3 Enterprise, WPA3/WPA2 Enterprise, WPA2 Enterprise,
WPA2/WPA Enterprise - The WPA encrypts each frame
transmitted from the radio using the key, which either PSK
(Pre-Shared Key) entered manually in this field below or
automatically negotiated via 802.1x authentication.
 WPA2 Enterprise - The WPA encrypts each frame transmitted
from the radio using the key, which either PSK (Pre-Shared Key)

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
