V-1 Introduction of DrayTek Wireless
VigorAP 906 supports Android/iOS APP : DrayTek Wireless. The mobile user can find the APP
through Apple App Store / Google Play Store.
After downloading the APP, a mobile user is able to access and login the configuration page of
VigorAP.

Note:
Before using the DrayTek Wireless APP, please ENABLE your Wi-Fi feature first. Then, select the
Wi-Fi network with Vigor access point(s) connected physically.
It is not necessary to connect to VigorAP physically. The mobile user must connect to one network
with the same subnet as the VigorAP.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
