Draytek VigorAP 906 User Manual

28
II-1 Operation Mode
This page provides several available modes for you to choose from for different conditions. Click
any one of them and click OK. The system will configure the required settings automatically.
Available settings are explained as follows:
Item Description
AP This mode allows wireless clients to connect to the access point and
exchange data with the devices connected to the wired network.
Mesh Mesh Root – VigorAP must connect to a gateway with an Ethernet
cable.
Mesh Node – VigorAP can connect to other mesh roots via the
wireless connection. A mesh network creates one set of links
automatically and calculates the most optimal wireless path through
the wireless network back to a wired mesh root.

Note:
The Wireless LAN settings will be changed according to the Operation Mode selected here. For
detailed information, please refer to the section of Wireless LAN.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
