Draytek VigorAP 906 User Manual

96
III-1-6 Syslog/Mail Alert
Syslog function is provided for users to monitor AP. There is no bother to directly get into the Web
user interface of the AP or borrow debug the equipment.
Available settings are explained as follows:
Item Description
Syslog Access Setup Enable - Check Enable to activate the function of Syslog.
Server IP Address -The IP address of the Syslog server.
Destination Port -Assign a port for the Syslog protocol. The default
setting is 514.
Log Level - Specify which level of the severity of the event will be
recorded by Syslog.
Mail Alert Setup Enable - Check Enable to activate the function of mail alert.
SMTP Server - The IP address of the SMTP server.
SMTP Server Port - Set the port number for the SMTP server.
Mail To - Assign a mail address for sending mails out.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
