Draytek VigorAP 906 User Manual

65
II-4-1 Mesh Setup
Such a page can determine the role of the VigorAP connecting to the computer physically. For a
mesh root, you can search and specify mesh nodes as members under the current mesh group.
Available settings are explained as follows:
Item Description
General Setup
Role Mesh Root – When VigorAP is connected to a Vigor router with a
physical Ethernet cable, it can be set as a mesh root to deliver the
wireless signals to a mesh node AP.
Mesh Node – As a mesh node, such VigorAP can pass the wireless
connection signal to another mesh node or a remote device (PC, CPE,
mobile phone).
In addition, VigorAP can be searched by mesh root AP and join the
mesh group of the root AP. The configuration, set for mesh root can
be applied to the mesh node.
Log Level – Choose Basic or Detailed. Related information will be
shown on the Diagnostics>>System Log.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
