Draytek VigorAP 906 User Manual

39
II-3-3 Access Control
For additional security of wireless access, the Access Control facility allows you to restrict the
network access right by controlling the wireless LAN MAC address of the client. Only the valid MAC
address that has been configured can access the wireless LAN interface. By clicking the Access
Control, a new web page will appear, as depicted below, so that you could edit the clients' MAC
addresses to control their access rights (deny or allow).
Available settings are explained as follows:
Item Description
Policy Select to enable any one of the following policies or disable the policy.
Choose Activate MAC address filter to type in the MAC addresses
for other clients in the network manually. Choose Blocked MAC
address filter, so that all of the devices with the MAC addresses listed
on the MAC Address Filter table will be blocked and cannot access into
VigorAP 906.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
