Draytek VigorAP 906 User Manual

124
IV-2 Applications
Below shows the menu items for Applications.
IV-2-1 Schedule
The VigorAP has a built-in clock that can update itself manually or automatically using Network Time
Protocols (NTP). As a result, you can not only schedule the AP to dial-up to the Internet at a specified
time but also restrict Internet access to certain hours so that users can connect to the Internet only
during certain hours, say, business hours. The schedule is also applicable to other functions.
You have to set your time before setting the schedule. In System Maintenance>> Time and
Date menu, press Inquire Time button to set the VigorAP’s clock to the current time of your PC. The
clock will reset once if you power down or reset the AP. There is another way to set up a time. You
can inquiry about an NTP server (a time server) on the Internet to synchronize the AP’s clock. This
method can only be applied when the WAN connection has been built up.
Available settings are explained as follows:
Item Description
Current System Time Display current system time.
System time set Click it to open the Time and Date page for configuring the time
setting.
Set to Factory Default Click it to return to the factory default setting and remove all the
schedule profiles.
Index Display the sort number of the schedule profile.
Enable Check it to enable the function of schedule configuration.
Name Display the name of the schedule.
Action Display the action adopted by the schedule profile.
Time Display the time setting of the schedule.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
