Draytek VigorAP 906 User Manual

123
Email (E) – Enter the email address for the root CA with a length of
fewer than 32 characters.
Key Type At present, only RSA (an encryption algorithm) is supported by such a
device.
Key Size To determine the size of a key to be authenticated, use the drop-down
list to specify the one you need.
Apply to Web HTTPS VigorAP needs a certificate to access the Internet via Web HTTPS.
Check this box to use the user-defined root CA certificate which will
substitute for the original certificate applied by web HTTPS.

Note:
“Common Name” must be configured with router's WAN IP or domain name.
After finishing this web page configuration, please click OK to save the settings. A new root CA will
be generated.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
