Draytek VigorAP 906 User Manual

127
IV-2-2 Wi-Fi Auto On/Off
When VigorAP is able or unable to ping the specified host, the Wi-Fi function will be turned on or off
automatically. The purpose of such function is to avoid wireless station roaming to an AP which is
unable to access the Internet.
Available settings are explained as follows:
Item Description
Enable Auto Switch
On/Off Wi-Fi
Check the box to enable such a function.
Ping Host Enter an IP address (e.g., 8.8.8.8) or a domain name (e.g., google.com)
for testing if the access point is stable or not.
Click OK to save the settings.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
