Draytek VigorAP 906 User Manual

126
In which, you have to specify the device object/device group profile for
blocking certain wireless clients when Internet Pause is selected as the
Action.
WiFi(2.4GHz)/
WiFi(5GHz)
When Wi-Fi UP or Wi-Fi DOWN is selected as Action, you can check
the Radio or SSID 2~4 boxes (2.4GHz and 5GHz respectively) to set up
the network based on the schedule profile.
Note: When Radio is selected, SSID2, SSID3, and SSID4 are not
available for choosing, vice versa. Moreover, SSID2, SSID3, and SSID4
are not available for choosing if they are not enabled.
Acts Specify how often the schedule will be applied.
Once -The schedule will be applied just once
Routine -Specify which days in one week should perform the
schedule.
Weekday Choose and check the day to perform the schedule. It is available
when the Routine is selected as Acts.
2. After finishing this web page configuration, please click OK to save the settings. A new
schedule profile has been created and displayed on the screen.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
