Draytek VigorAP 906 User Manual

97
Mail From - Assign a path for receiving the mail from outside.
User Name - Type the user name for authentication.
Password - Type the password for authentication.
SSL - Check this box to enable SSL certificate for the SMTP server.
StartTLS - Check this box to encrypt alert mail. However, if the SMTP
server specified here does not support TLS protocol, the alert mail
with encrypted data will not be received by the receiver.
Enable E-Mail Alert - VigorAP will send an e-mail out when a user
accesses the user interface by using web or telnet.
When Admin Login AP – Enable/disable the function. When it is
enabled, VigorAP will send out an e-mail to the recipient defined
above when a user tries to access VigorAP by entering login username
and password.
Click OK to save the settings.
III-1-7 Time and Date
It allows you to specify where the time of VigorAP should be inquired from.
Available parameters are explained as follows:
Item Description
Current System Time Click Inquire Time to get the current time.
Enable NTP Client Select to inquire time information from Time Server on the Internet
using the assigned protocol.
Time Zone Select a time protocol.
NTP Server Type the IP address of the time server.
Use Default – Click it to choose the default NTP server.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
