Draytek VigorAP 906 User Manual

48
After finishing this web page configuration, please click OK to save the settings.

Note:
Airtime Fairness function and Bandwidth Limit function should be mutually exclusive. So their
webs have extra actions to ensure these two functions are not enabled simultaneously.
II-3-10 Station Control
Station Control is used to specify the duration for the wireless client to connect and reconnect
VigorAP. If such a function is not enabled, the wireless client can connect VigorAP until it shuts
down.
Such a feature is especially useful for free Wi-Fi service. For example, a coffee shop offers free Wi-Fi
service for its guests for one hour every day. Then, the connection time can be set as “1 hour” and
reconnection time can be set as “1 day”. Thus, the guest can finish his job within one hour and will
not occupy the wireless network for a long time.

Note:
Up to 300 Wireless Station records are supported by VigorAP.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
