Draytek VigorAP 906 User Manual

49
Available settings are explained as follows:
Item Description
SSID Display the SSID that the wireless station will use to connect with the
Vigor router.
Enable Check the box to enable the station control function.
Connection Time /
Reconnection Time
Use the drop-down list to choose the duration for the wireless client
connecting /reconnecting to the Vigor device. Or, type the duration
manually when you choose User-defined.
Display All Station
Control List
All the wireless stations connecting to the Vigor router by using such
SSID will be listed on Station Control List.
After finishing all the settings here, please click OK to save the configuration.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
