Draytek VigorAP 906 User Manual

117
Item Description
SSID Policy Determine the policy (disable, white list, or black list) applied for the
SSID (1 to 4).
From to list Device MAC - Display the MAC address of the selected station.
Name - Display the name of the selected station.
Apply to SSID - Check the box(es) to apply the SSID to the selected
station.
Close - Exit the dialog without saving the changes.
Save changes - Save the changes and exit the dialog.
III-3-4 Policies
This page determines which devices (mobile, PC, MAC, or others) allowed to make network
connections via VigorAP or blocked by VigorAP.
Each item is explained as follows:
Item Description
Block Mobile
Connections
All mobile devices will be blocked and not allowed to access the
Internet via VigorAP.
Block PC Connections All network connections based on PC, MAC, or Linux platforms will be
blocked and terminated.
Block Unknown
Connections
Only the unknown network connections (unable to be recognized by
the Vigor router) will be blocked and terminated.
WiFi(2.4GHz) Specify the SSID(s) to apply such policy.
WiFi(5GHz) Specify the SSID(s) to apply such policy.
After finished the policy selection, click OK. VigorAP will reboot to activate the new policy
automatically.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
