Draytek VigorAP 906 User Manual

157
VI-3 Checking the Network Connection Settings
Sometimes the link failure occurs due to the wrong network connection settings. After trying the
above section, if the link is stilled failed, please do the steps listed below to make sure the network
connection settings are OK.
VI-3-1 For Windows

Note:
The example is based on Windows 7 (Professional Edition). As to the examples for other operating
systems, please refer to the similar steps or find support notes in www.draytek.com.
1. Open All Programs>>Getting Started>>Control Panel. Click Network and Sharing
Center.
2. In the following window, click Change adapter settings.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
