Draytek VigorAP 906 User Manual

38
Click the link of RADIUS Server to access into the following page for more settings.
Available settings are explained as follows:
Item Description
Use internal RADIUS
Server
There is a RADIUS server built in VigorAP 906 which is used to
authenticate the wireless client connecting to the access point. Check
this box to use the internal RADIUS server for wireless security.
Besides, if you want to use the external RADIUS server for
authentication, do not check this box.
Please refer to the section, IV-1-1 RADIUS Server to configure settings
for internal server of VigorAP 906.
IP Address Enter the IP address of the external RADIUS server.
Port The UDP port number that the external RADIUS server is using. The
default value is 1812, based on RFC 2138.
Shared Secret The external RADIUS server and client share a secret that is used to
authenticate the messages sent between them. Both sides must be
configured to use the same shared secret.
Session Timeout Set the maximum time of service provided before re-authentication.
Set to zero to perform another authentication immediately after the
first authentication has been completed. (The unit is second.)
After finishing this web page configuration, please click OK to save the settings.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
