Draytek VigorAP 906 User Manual

112
control.
Apply to SSID - Check All to make the device apply the policies to all
SSIDs. Or select the one(s) to make the device apply the policies to
the selected SSIDs.
Close - Exit this page without saving any changes.
Save changes - Save the changes and exit this page.
+Device Object To add a device to the device object list, choose one of the entries
(clients) on the Clients List to enable the Device Object button. Click
the button to open the following page.
Check the information listed on the page. Change the MAC address
or name of the selected entry if required. Then click OK and exit the
page.
Device Object list The existed device object profiles will be shown on the following
page.
Clients List Display the stations connecting to this Vigor device.
Total Usage - Display
Total Clients - Display the number of the clients using 2.4GHz
Name / MAC - Display the host name / MAC address of the
connecting client.
Up Time - Display the connection time.
Link Speed - Display the link speed.
RSSI - Display the RSSI value.
SSID - Display the SSID the client used for connecting VigorAP.
OS - Display the OS of the client.
Usage - Display the bandwidth usage (up and down) of the client.
CH - Display the channel used by the client.
Action - Display the authentication method used by the client, and if
it is on the block list or white list.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
