Draytek VigorAP 906 User Manual

19
day.
2nd WiFi Name - Set a name for VigorAP 906 which can be identified
and connected by a wireless guest.
2nd WiFi Password - Set 8~63 ASCII characters which can be used for
logging into VigorAP 906 by a wireless guest.
Enable
Bandwidth Limit
Check the box to define the maximum speed of the data
uploading/downloading which will be used for the guest connecting to
the Vigor device with the same SSID.
Upload Limit – Scroll the radio button to choose the value you want.
Download Limit –Scroll the radio button to choose the value you
want.
Enable Station
Control
Check the box to set the duration for the guest connecting
/reconnecting to the Vigor device.
Connection Time –Scroll the radio button to choose the value you
want.
Reconnection Time –Scroll the radio button to choose the value you
want.
3. Change the default password for such a device with a new value. Then click Next Step.
Available settings are explained as follows:
Item Description
Admin Password Enter a new password.
Confirm
Password
Enter the new password again for confirmation.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
