30
It is the simplest way to build a connection between wireless network clients and VigorAP 906. Users
do not need to select any encryption mode and type any long encryption passphrase to set up a
wireless client every time. He/she only needs to press a button on wireless client, and WPS will
connect for client and VigorAP 906 automatically.
Note:
Such function is available for the wireless station with WPS supported.
There are two methods to do network connection through WPS between AP and Stations: pressing
the Start PBC button or using PIN Code.
On the side of the VigorAP 906 series which served as an AP, press the WPS button once on the
front panel of VigorAP 906 or click Start PBC on the web configuration interface. On the side of a
station with a network card installed, press the Start PBC button of a network card.
If you want to use a PIN code, you have to know the PIN code specified in the wireless client. Then
provide the PIN code of the wireless client you wish to connect to the VigorAP 906.
