Draytek VigorAP 906 User Manual

34
Available settings are explained as follows:
Item Description
Enable Wireless LAN Check the box to enable the wireless function.
Enable Client Limit Check the box to set the maximum number of wireless stations which
try to connect the Internet through the Vigor device. The number you
can set is from 3 to 64.
Enable Client Limit per
SSID
Define the maximum number of wireless stations per SSID which try
to connect to the Internet through the Vigor device. The number you
can set is from 3 to 64.
Mode At present, VigorAP 906 can connect to 11n only, 11a only, 11n only
(5G), Mixed (11b+11g), Mixed (11b+11g+11n) and Mixed
(11b+11g+11n+11ax) stations simultaneously. Simply choose Mixed
(11b+11g+11n+11ax) mode.
(2.4 GHz)
(5GHz)
Channel Means the channel of frequency of the wireless LAN. You may switch
the channel if the selected channel is under serious interference. If
you have no idea of choosing the frequency, please
select AutoSelect to let the system determine for you.
Extension Channel With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be varied
according to the Channel selected above. Configure the extension
channel you want.
Enable 2 Subnet
(Simulate 2 APs)
Check the box to enable the function for two independent subnets.
Once you enable this function, LAN-A and LAN-B would be
independent. Next, you can connect one router in LAN-A, and another
router in LAN-B. Such a mechanism can make you feel that you have
two independent AP/subnet functions in one VigorAP 906.
If you disable this function, LAN-A and LAN-B ports are in the same
domain. You could only connect one router (no matter connecting to
LAN-A or LAN-B) in this environment.
Hide SSID Check it to prevent wireless sniffing and make it harder for
unauthorized clients or STAs to join your wireless LAN. Depending on
the wireless utility, the user may only see the information except for

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
