Draytek VigorAP 906 User Manual

53
Open Wireless LAN (2.4GHz)>>Band Steering to get the following web page:
Available settings are explained as follows:
Item Description
Enable Band Steering If it is enabled, VigorAP will detect if the wireless client is capable of
dual-band or not within the time limit.
Check Time…. – If the wireless station does not have the capability of
a 5GHz network connection, the system shall wait and check for
several seconds (15 seconds, in default) to make the 2.4GHz network
connection. Specify the time limit for VigorAP to detect the wireless
client.
5GHz Minimum RSSI – The wireless station has the capability of a
5GHz network connection, yet the signal performance might not be
satisfied. Therefore, when the signal strength is below the value set
here while the wireless station connecting to VigorAP 906, VigorAP will
allow the client to connect to the 2.4GHz network.
After finishing this web page configuration, please click OK to save the settings.

Draytek VigorAP 906 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Placement	Ceiling, Table, Wall
Product color	White
Security algorithms	WEP, WPA, WPA2, WPA3, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	5
Antenna type	External
Antenna direction type	Omni-directional
Antenna gain level (max)	2.5 dBi
Input current	0.4 A
Output current	1.5 A
AC input voltage	48 - 56 V
DC voltage range	12 V
Power consumption (max)	17.3 W
Sustainability certificates	CE
