143
x Platemaking / Master Feed / Ejection Section
chap.4
Before adjustment
C mode adjustment must be carried
out After B mode adjustment
has been completed.
IMPORTANT :
Adjustment procedure
1. Remove the drum from the machine body.
3. Turn off the power, and install the drum to the
machine body.
4. Access HELP - 012.
HELP - 012 \ see p.226
¡C mode
¡Stopping drum in master detachment position
(3) Adjusting the B / C Mode
¡When drum is removed from main body ( B mode )
5. Press and hold down the "1" key to set the detach
position.
6.
Press and hold down the (PRINT POSITION) key
to set the master clamp open/close lever to the C
mode position.
2. Access HELP - 012.
For the accessing HELP modes :
Press and hold down the (PRINT POSITION) key
to set the master clamp open/close lever to the B
mode position.
\See page 199
HELP - 012 \ see p.226
R8S04011
R8S04012
R8S04013
