Duplo DP-S Series - Function of Parts; Thermal Head

DP-S550 DP-S520 / S510 DP-S850 DP-S620DP-S650
292.6 0.1mm
Item
39
x Platemaking / Master Feed / Ejection Section
chap.2
(1)Thermal Head
Description
The thermal elements are in alignment in the primary scanning (vertical direction), and are heated on the
image section to make holes on the master film.
Specifications
Circuit
3. Functions of Parts
R8S02E07
No.
1 Picture element density 600DPI (23.6dot/mm)
2 Effective memory width
300DPI ( 11.81dot/mm ) 400DPI ( 15.7dot/mm )
260.1 0.1mm
300DPI ( 11.81dot/mm )
260.2 0.2mm
400DPI (15.7dot/mm)
