NameNo. Function
RESET key
PRINT DARKNESS keys
PRINT POSITION keys
PRINT SPEED keys
ENERGY SAVE key
LCD BRIGHTNESS ADJUST DIAL
TEST PRINT key
STOP key
PRINT key
MASTER MAKING key
key
NUMERIC keys
CLEAR key
PROPERTY key
Returns setting to standard mode.
Setting not stored is cleared.
Controls print darkness.
Controls print position (horizontal/vertical).
* PRINT POSITION keys for horizontal are not available on DP-S550/S520/S510.
Controls print speed.
Turns the LCD panel OFF. (Reduces standby power consumption.)
Controls brightness of the LCD.
Prints 1 copy to check the image position and density.
Stops printing.
When this key is pressed during making a master, the machine stops
after making a master.
Starts printing. This key does not start making a master.
Printing cannot start when the light of the PRINT key is red
(When confidential function is set, when a master is not set on the drum,
when error is displayed, when the number of print is not entered).
Starts making a master. Master making cannot be performed during printing.
Clear the number of print before master making.
Enters the print and group number in batch printing.
Enters the print volume.
Returns the print volume to 0. Other settings on the control panel
are not changed. Press to use special functions.
NameNo. Function
LCD (touch panel)
LAMP
Clip holder
Pen holder
Displays current settings such as number of printed sheet.
Touch to change settings. Displays error messages in case of error.
Blinks to indicate the status of the machine. Green: Operating.
Red: Error message is displayed. Orange: Message replacing consumables is displayed.
-
-
