v Part Names and Their Functions
chap.1
18
Master feed section
Press this button rotates the drum and stops it in
position to be removed. And then LED gose on.
Cutter
Master roll
Master cover
LED
Drum removal button
Drum handle
Ink holder
Ink puck
Scanner switch
Master Cover Release Lever
Press the lever to open the master cover
when the master roll is setted up.
Scanner unit
R8S01004e
