Duplo DP-S550 User Manual

Standard value
164
, Electrical system
chap.4
(6) Adjusting of Printer Unit's Printing Speed
Adjustment procedure
1. Access HELP-003.
2. Touch the PRESTOP SPEED.
3. Press the (MASTER MAKING) key. The drum
rotates and the rotation speed appears on the panel
lower part.
Standard values:
HELP - 003 \ see p.203
1. Adjusting the Pre-stop Speed
Item
Pre-stop speed 6 rpm
If the value is not correct:
¡Press the (PRINT POSITION) , keys to obtain
the proper value in 3 above.
Press the (PRINT POSITION) key once: By 1 rpm
decreased
Press the (PRINT POSITION) key once: By 1 rpm
increased
4. Press the key to store all speed set values.
Initialization
¡Press the (CLEAR) key to initialize the displayed
value.
¡HELP-003 display : Pre-stop speed
2.
Adjusting the M-mark Speed
¡HELP-003 display : M-mark Speed
Standard value
Adjustment procedure
1. Access HELP-003.
2. Touch the M-MARK SPEED.
3. Press the (MASTER MAKING) key. The drum
rotates and the rotation speed appears on the panel
lower part.
Standard values:
HELP - 003 \ see p.203
Item
M-mark Speed 18 rpm
If the value is not correct:
¡Press the (PRINT POSITION) , keys to obtain
the proper value in
3 above.
Press the (PRINT POSITION) key once: By 1 rpm
decreased
Press the (PRINT POSITION) key once: By 1 rpm
increased
4. Press the key to store all speed set values.
Initialization
¡Press the (CLEAR) key to initialize the displayed
value.
