198
c HELP Mode Function and Operation Procedures
chap.7
x Overview
The DUPRINTER's HELP modes can be broadly classified into the
following types:
â—† Modes for ROM version display / version upgrade
To display the tape cluster ROM version if the main PCB ROM,
the panel PCB ROM, FPGA and the tape cluster TAP-05 - 12 are
available
To update the main PCB ROM and the panel PCB ROM.
â—† Modes for adjustment / specification setting
These modes set the functioning of variable resistors and switches
by using the battery PCB unit's EEPROM to memorize settings
made on the operation panel. All of these adjustments and settings
are made at the factory prior to shipment of each DUPRINTER.
¡New adjustments and appropriate settings must be made after
the battery PCB unit is replaced and after initialization setting
has been implemented (using HELP-027).
â—† Modes for function checks
These modes permit the running of function checks on:
individual motors, given series of operations, and electrical
circuits.
When these modes are used to check motor functioning, the
motor being checked is run by itself, but interlocks are
suspended. When such checks are run, take care not to put
hands or fingers in motor-related moving parts that could start
up unexpectedly.
IMPORTANT :
â—† Modes for sensor and switch displays
These modes provide displays of the conditions of sensors and
switches.
â—† Modes for total count displays
These modes provide displays of the counts of the total number of
plates made and sheets printed by the DUPRINTER since it was
manufactured. They also permit resetting of the total count values
displayed in the user mode.
¡Failure to heed the above could
result in crushed or otherwise
injured hands or fingers.
WARNING
To Next Page
