94
m Drum Section
chap.2
(5) Fine Start Mode
This mode automatically sets optimum values for the following start conditions: timing of ink roller actuation
during platemaking, number of no-paper rotations with the ink roller actuated.
These optimum settings are based on room temperature, the length of time the printer was out of use, and the
number of prints last time it was used. They ensure clear printing right from the first sheet after platemak-
ing.
*Room temperature of 10; or below can cause insufficient ink supply, even in Fine Start.
Standby state The cam turns a half-revolution, so that the ink
roller is pressed against the drum inner surface.
Then the drum rotates.
The cam turns a half-revolution, so that the ink roller
moves out of contact with the drum inner surface.
Printing begins.
Cam
Ink
Roller
Drum
Ink roller
Squeegee
roller
Operation
R8S02087 R8S02088
R8S02089 R8S02090
