211
c HELP Mode Function and Operation Procedures
chap.7
(1)
Adjusting/Checking the Paper Feed Section
(3 pages in total)
Page 1 :
2
Check operation.
ELEVATOR MOTOR / PAPER FEED STEPPING MOTOR
2
Checking sensors/switches.
ELEVATOR TOP LIMIT SENSOR / ELEVATOR LOWER LIMIT SWITCH / ELEVATOR DOWN SWITCH / PAPER
SENSOR / PAPER TOP DETECT SENSOR / SIGNAL SENSOR / HEAVY WEIGHT PAPER LEVER SENSOR
¡ Operation procedure
3.
Check the following sensors and switches.
Checking sensors/switches.
2.
Check operation.
2
Check operation.
1.
Enter
“
006
”
by the
NUMERIC
keys and then press the
(PRINT)
key.
Call the HELP mode
“
H-006
”
.
step 4.
a
Press the
(STOP)
key.
To Next Page
