Operation
24 Operating Instructions 1767 - 00.0 - 12/2016
8. Guide the needle thread clockwise around the thread tension-
ing spring (3).
Fig. 7: Needle thread threading on 1-needle machines (2)
9. Guide the needle thread under the spring of the thread ten-
sioning spring (3).
(3) - Thread tensioning spring
(9) - Thread lever
(10)- Thread guide,
optional: Thread clamp
(11)- Thread guide
(12)- Needle thread regulator
