Maintenance
76 Operating Instructions 1767 - 00.0 - 12/2016
3. Loosen the drain screw (3) completely.
4. Allow water to drain into the collection tray.
5. Tighten the drain screw (3).
6. Connect the machine to the compressed air supply.
6.3.3 Cleaning the filter element
Fig. 33: Cleaning the filter element
To clean the filter element:
1. Disconnect the machine from the compressed air supply.
NOTICE
Damage to the paintwork from solvent-based cleaners!
Solvent-based cleaners damage the filter.
Use only solvent-free substances for washing out the filter
tray.
(1) - Filter element
(2) - Water separator
(3) - Drain screw
