Setup
Operating Instructions 1767 - 00.0 - 12/2016 93
2. Loosen the screw (2).
3. Remove the toothed lock washer (4).
4. Guide the grounding wire of the control (1) to the rear of the
control through the cutout in the tabletop.
5. Tighten the grounding wire of the control (1) along with the
grounding wire of the motor (3) under the toothed washer (4)
using the screw (2).
7.11 Pneumatic connection
The pneumatic system of the machine and of the additional equip-
ment must be supplied with dry and oil-free compressed air.
The supply pressure must lie between 8 and 10 bar.
NOTICE
Property damage from oily compressed air!
Oil particles in the compressed air can cause malfunctions of
the machine and soil the sewing material.
Ensure that no oil particles enter the compressed air supply.
NOTICE
Property damage from incorrect setting!
Incorrect system pressure can result in damage to the
machine.
Ensure that the machine is only used when the system
pressure is set correctly.
