Operation
Operating Instructions 1767 - 00.0 - 12/2016 41
4.9.4 Setting the sewing foot stroke
Limiting of number of stitches with an increased sewing
foot stroke
Information
The machine has a potentiometer on the arm shaft.
The potentiometer automatically adapts the number of stitches to
the sewing foot stroke: If you increase the sewing foot stroke, the
number of stitches is automatically reduced.
Fig. 21: Setting the height of the sewing foot stroke
NOTICE
Property damage may occur!
Damage to the machine through an excessively high number
of stitches with an increased sewing foot stroke.
Ensure that the number of stitches specified in the appendix
tables for the respective combination of stitch length and
sewing foot stroke is not exceeded.
Do not change the setting of the potentiometer.
(1) - Sewing foot stroke adjusting wheel
